Hanwha Vision ANO-L7012R, 4MP IR Bullet Camera

$220.00

SKU:: ANO-L7012R

Usually Ships: 1-2 Business Days

Low Prices

Superior Selection

In Stock and Ready to Ship

Have a question or need a quote?

SSL Secure Payment

We take pride in our swift and efficient order processing. Rest assured, once you place your order, it will be promptly processed and dispatched the very next working day.

Description
Resources
Reviews

Hanwha Vision ANO-L7012R, 4MP IR Bullet Camera

2 megapixel (1920 x 1080) resolution
Built-in 3mm fixed lens
30fps@ all resolutions (H.265/H.264)
H.265/H.264, MJPEG codec supported, Multiple streaming
Day & Night (ICR), WDR (120dB)
Virtual Line Crossing/Directional Detection, Enter/Exit, Tampering, Motion detection
Micro SD/SDHC memory slot (Max. 32GB), PoE
Hallway view, WiseStream II support
IR viewable length 20m
IP67,IK10 support

Specifications

Video
Imaging Device																																																																1/2.8" CMOS
Resolution																																																																1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
Max. Framerate																																																																H.265/H.264 : Max. 30fps/25fps(60Hz/50Hz) MJPEG : Max. 10fps
Min. Illumination																																																																Color: 0.03Lux(F1.6, 1/30sec) BW : 0Lux (IR LED on)
Lens
Focal Length (Zoom Ratio)																																																																3mm fixed focal
Max. Aperture Ratio																																																																F1.6
Angular Field of View																																																																H: 107.7° / V: 59.0° / D: 126.7°
Min. Object Distance																																																																1.1m(3.6ft)
Focus Control																																																																Fixed
Pan / Tilt / Rotate
Pan / Tilt / Rotate Range																																																																0°~350° / 0°~67° / 0°~355°
Operational
Camera Title																																																																Displayed up to 15 characters
Day & Night																																																																Auto(ICR)
Backlight Compensation																																																																BLC, WDR, SSDR
Wide Dynamic Range																																																																120dB
Digital Noise Reduction																																																																SSNR
Motion Detection																																																																4ea, rectangler zones
Privacy Masking																																																																6ea, rectangular zones
Gain Control																																																																Low / Middle / High
White Balance																																																																ATW / AWC / Manual / Indoor / Outdoor
LDC																																																																Support
Electronic Shutter Speed																																																																Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation																																																																Flip, Mirror, Hallway view(90˚/270˚)
Analytics																																																																Motion detection, Tampering, Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction)
Alarm Triggers																																																																Analytics
Alarm Events																																																																File upload via FTP and e-mail Notification via e-mail SD/SDHC recording at event triggers
IR Viewable Length																																																																20m(65.62ft)
Network
Ethernet																																																																RJ-45(10/100BASE-T)
Video Compression																																																																H.265/H.264 : Main/High, MJPEG
Smart Codec																																																																WiseStreamⅡ
Bitrate Control																																																																H.265/H.264: CBR or VBR MJPEG: VBR
Streaming																																																																Unicast(6 users) / Multicast Multiple streaming (Up to 3 profiles)
Protocol																																																																IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour
Security																																																																HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP)
Application Programming Interface																																																																ONVIF Profile S/G/T SUNAPI(HTTP API)
General
Webpage Language																																																																English
Edge Storage																																																																Micro SD/SDHC 1slot 32GB
Memory																																																																512MB RAM, 256MB Flash
Environmental & Electrical
Operating Temperature / Humidity																																																																-30°C ~ +55°C(-22°F ~ +131°F) / Less than 95% RH * Start up should be done at above -20°C(-4°F)
Storage Temperature / Humidity																																																																-30°C ~ +55°C(-22°F ~ +131°F) / Less than 95% RH
Certification																																																																IP67, IK10
Input Voltage																																																																PoE(IEEE802.3af, Class3)
Power Consumption																																																																Max 6.6W, Typical 4.8W
Mechanical
Color / Material																																																																White / Plastic, Aluminum
RAL Code																																																																RAL9003
Product Dimensions / Weight																																																																Ø125.0x87.4mm(Ø4.92x3.44"), 630g
Compatible Conduit hole / Gangbox																																																																None / Single, Double, 4" Octagon
Backbox																																																																SBV-A14B
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF)																																																																28.1m(92.04ft)
Observe (63PPM/ 19PPF)																																																																11.2m(36.82ft)
Recognize (125PPM/ 38PPF)																																																																5.6m(18.41ft)
Identify (250PPM/ 76PPF)																																																																2.8m(9.20ft)
