Camden CM-RQE70A, PIR ‘Request to Exit’ Detector, White

Camden's CM-RQE70A PIR 'REQUEST TO EXIT' Detectors provide the latest word in design, with a complete list of "high performance" features, including secondary activation device input, door monitoring, two relay outputs, and tamper alarm. Many new programming, installation, and set-up features that have never previously been available.

Camden started by making the CM-RQE70A smaller, so it can easily fit on door frames, and then made installing the detector faster and easier. CM-RQE70A comes with 4 factory default operating modes that can be selected with simple push buttons on the circuit board.

Have an unusual installation and need custom settings? No problem. You can use the on-board push buttons to customize the default operating modes or program your own custom operating mode. CM-RQE70A isn't just a new REX detector, it's a whole new approach to REX detector design!

  • Programming Buttons w/ Factory Default Modes
  • On-Board Wiring Terminal
  • Sized To Fit Door Frames
  • Part of Our Touchless Wave Product Family

   Table Of Specification

Voltage:



12/24 VDC Operation

Current Draw:

50 mA (Max)

Relays:

(2) Form ‘C’ (DPDT)

Contact Rating:

3 A @ 30 VDC

Programming:

On-board push buttons and status LED

Modes:

(4) Factory Default
(1) Fully Custom
Selectable Fail Safe/Fail Secure

Coverage:

Max. 10’W x 10’H
Horizontal and Vertical Adjustment (Mechanical)
Sensor Sensitivity/Range (Electronic)

Time Delay:

Adjustable, 5, 15, 30, 45 & 60 second

Sounder:

ON/OFF, with Adjustable Volume

Piezo Buzzer:

92 db. @ 10cm

Indicator:

Activation LED

Card or Keypad Input:

(1) N/O

Door Position Switch Input:

(1)  N/O

Request to Exit Input:

(1) N/O

Tamper Switch Contact Rating:

50 mA 12 VDC



Temp Operating Range:

32°F-120°F (0-50°C)

Humidity Range:

0- 93% Non-Condensing

Dimensions:

1-3/4"H x 7"W X 1-3/4"D
(43mm x 176mm x 43mm)

Weight:

0.25 Lbs. (0.12 Kg.)

Colors:

White or Black Models
